DZR Brass

Description

2 Piece DZR Brass Ball Valve. Full Bore.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-20°C to +130°C

Description

2 Piece DZR Brass Ball Valve. Full Bore.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Pressure

40 Bar Rated

Temperature

-20°C to +130°C

Description

DZR Brass Ball Valve. Full Bore.

Connection

Compression Ends (BS EN 1254-2 (1998))

Approvals/ other

WRAS Approved

Pressure

25 Bar Rated

Temperature

-10°C to +110°C

Description

DZR Brass Ball valve. Full Bore. Thermal extension available. 5 year warranty.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M & V Profiles 42mm & 54mm

Approvals/ other

CE Approved
WRAS Approved

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-20°C to +140°C

Description

PN20 DZR Brass Gate Valve. Full Bore. Handwheel Operation.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

BS 5154 Approved
WRAS Approved

Pressure

20 Bar Rated

Temperature

-20°C to +170°C

Description

PN20 DZR Brass Gate Valve. Full Bore. Lockshield - Key available separately.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

BS 5154 Approved
WRAS Approved

Pressure

20 Bar Rated

Temperature

-20°C to +170°C

Description

DZR Brass Single Check Valve. F/F BSP Parallel (ISO 228/1). Conforms with EN13959. Suitable for Fluid Categories 1 & 2.

Connection

F/F BSP Parallel (ISO 228/1)

Pressure

16 Bar Rated

Temperature

Max Working Temp: +85°C

Description

DZR Brass Single Check Valve. Compression Ends (EN1254-2). Conforms with EN13959. Suitable for Fluid Categories 1 & 2.

Connection

Compression Ends (EN1254-2)

Approvals/ other

Conforms with EN13959

Pressure

10 Bar Rated

Temperature

Max Working Temp: +85°C

Description

DZR Brass Double Check Valve. BSP Parallel F/F Ends. WRAS Approved. Conforms with EN13959. Suitable for Fluid Categories 1, 2 & 3.

Connection

BSP Parallel (ISO 228/1)

Approvals/ other

WRAS Approved

Conforms with EN13959.

Pressure

16 Bar Rated

Temperature

-10°C to +85°C

Description

DZR Brass Double Check Valve. Compression Ends. WRAS Approved. Conforms with EN13959. Suitable for Fluid Categories 1, 2 & 3.

Connection

Compression Ends

Approvals/ other

WRAS Approved.
Conforms with EN13959

Pressure

10 Bar Rated

Temperature

-10°C to +85°C

Description

DZR Brass Y Type Strainer. EPDM Seat.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

CE Approved
5 year warranty.

Pressure

20 Bar Rated (DN15 to DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +150°C

Description

DZR Brass Ball Valve. Full Bore. Thermal extension available. 5 year warranty.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M & V Profile 42mm & 54mm

Approvals/ other

CE Approved
WRAS Approved

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-20°C to +140°C

Description

DZR Fixed Orifice Double Regulating Valve (FODRV). Handwheel with shut off function and clear 360° reading. Digital scale with lock function. Fixed orifice with ± 5% flow measurement accuracy. Conforms to BS 5154.

Stock Availability

Sizes 15L and 15ML subject to factory lead time.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 year warranty

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

0°C to +120°C

Description

DZR Double Regulating Valve (DRV). Handwheel with shut off function and clear 360° reading. Digital scale with lock function.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 year warranty

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +120°C

Description

DZR Fixed Orifice Double Regulating Valve (FODRV). Conforms to BS 5154. Fixed orifice with ±5% flow measurement accuracy

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 Year Guarantee

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +120°C

Description

DZR Double Regulating Valve (DRV). Handwheel with shut off function and clear 360° reading. Digital scale with lock function. Conforms to BS 5154.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 year warranty

Pressure

20 Bar Rated (DN15 to DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +120°C

Description

DZR Brass Y Type Strainer. EPDM Seat.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

CE Approved
5 year warranty.

Pressure

20 Bar Rated (DN15 to DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +150°C

Description

DZR Fixed Orifice Double Regulating Valve. Handwheel with shut off function and clear 360° reading. Digital scale with lock function. Conforms to BS 5154.

Connection

BSP Parallel (ISO 228 Threads) F/F Ends

Approvals/ other

WRAS Approved

Pressure

25 Bar

Temperature

-10°C to +120°C

Description

DZR Fixed Orifice Double Regulating Valve (FODRV). Handwheel with shut off function and clear 360° reading. Digital scale with lock function. Fixed orifice with ± 5% flow measurement accuracy. Conforms to BS 5154.

Stock Availability

Sizes 15L and 15ML subject to factory lead time.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 year warranty

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

0°C to +120°C

Description

DZR Double Regulating Valve (DRV)

Connection

BSP Parallel (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

Up to 25 Bar.

Temperature

-10°C to +120°C

Description

DZR Double Regulating Valve (DRV). Handwheel with shut off function and clear 360° reading. Digital scale with lock function.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 year warranty

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +120°C

Description

DZR Brass Fixed Orifice Double Regulating Valve. EPDM Seat

Connection

BSP Parallel F/F Ends (ISO 7/1)

Approvals/ other

5 Year Guarantee

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass Fixed Orifice Double Regulating Valve. EPDM Seat. Conforms to BS 5154.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 Year Guarantee

Pressure

24 Bar Rated (DN15), 20 Bar Rated (DN22 & DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +120°C

Description

DZR Brass Double Regulating Valve. EPDM Seat. Low flow version available in ½"

Connection

BSP Parallel F/F Ends (ISO 7/1)

Approvals/ other

5 Year Guarantee

Pressure

20 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Double Regulating Valve (DRV). Handwheel with shut off function and clear 360° reading. Digital scale with lock function. Conforms to BS 5154.

Connection

Universal M & V Profile 15mm to 35mm
Dedicated M Profile 42mm & 54mm

Approvals/ other

5 year warranty

Pressure

20 Bar Rated (DN15 to DN28), 17 Bar Rated (DN35 to DN54)

Temperature

-10°C to +120°C

Description

DZR Brass Variable Orifice Double Regulating Valve. EPDM Seat. Conforms to BS 7350 / BS 5154.

Connection

BSP Parallel F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

WRAS Approved
5 Year Guarantee

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass Orifice Plate. Fixed Orifice. Standard, Medium, Low, Ultra Low and Ultra Ultra Low versions available in ½".

Connection

BSP Parallel (½") Taper (¾ - 2") M/F Ends (ISO 7/1)

Approvals/ other

5 Year Guarantee

Pressure

20 Bar Rated

Temperature

-10°C to +120°C

Description

Thermostatic Balancing Valve with Anti Legionella Device. WRAS Approved. Fluid: Water. Automatic legionella disinfectant feature. Improves efficiency of DHW systems. Automatic regulation. Reduces heat loss through lower circulation of hot water. Helps to keep temperature evenly distributed and reduces dead-legs.

Connection

BSP Parallel (ISO 7/1)

Approvals/ other

WRAS Approved

Pressure

Max working pressure (Static): 25 Bar

Temperature

Working temperature: 40°C to 60°C
Max Inlet temperature: 90°C
Anti Legionella temperature: 70°C

Description

DZR Pressure Independent Control & Balancing Valve (PICV). Union Tail Pieces & Gaskets required (2 per valve for BSP male connection)

Connection

Screwed BSP Parallel (ISO 228/1)

Approvals/ other

5 Year Guarantee

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Pressure Independent Control and Balancing Valve (PICV)

Connection

BSP Parallel (ISO 228/1)

Approvals/ other

5 Year Guarantee

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

2 Piece Union & gasket to suit ART 20C Valves DN10-25 2 required per ART 20C

Description

DZR Automatic Flow Balancing Valve

Stock Availability

Subject to factory lead time.

Connection

Threaded BSP Parallel (ISO 7/1)

Approvals/ other

5 Year Guarantee

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

H Block complete with PICV. For direct mounting to terminal units in heating and cooling applications at 40mm centres. Integral Venturi metering station. Left and right hand versions available. Albion’s 0-10V modulating actuator (ART C23E) can also be added to the PICV for proportional control.

Connection

BSP Female x Union Solder

Pressure

Max Pressure: 20 Bar
Differential Pressure: 800kPa (8 Bar)

Temperature

0°C to +120°C

Description

H Block complete with PICV and Strainer. For direct mounting to terminal units in heating and cooling applications at 40mm centres. Integral Venturi metering station. Left and right hand versions available. Albion’s 0-10V modulating actuator (ART C23E) can also be added to the PICV for proportional control.

Connection

BSP Female x Union Solder

Pressure

Max Pressure: 20 Bar
Differential Pressure: 800kPa (8 Bar)

Temperature

0°C to +120°C

Description

H Block complete with PICV and Strainer. For heating and cooling applications at 80mm centres. Optional integral Venturi metering station. Left and right hand versions available.

Pressure

Max Pressure: 25 Bar Maximum Differential Pressure: 800kPa (8 Bar)

Temperature

0°C to +120°C

Description

H Block complete with FODRV. For heating and cooling applications at 80mm centres.

Pressure

Max Pressure: 25 Bar Maximum Differential Pressure: 800kPa (8 Bar)

Temperature

0°C to +120°C

Description

DZR Brass H Block with ART 25. Tested in accordance with EN12266-1:2012. 5 year guarantee.

Connection

Screwed BSP Connections.

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass H Block with ART 20C PICV. Tested in accordance with EN12266-1:2012. Flow modulation along with whole control actuator stroke (ART C21V, C22V, C23E). 5 year guarantee.

Connection

Screwed BSP Connections.

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass H Block with ART 20 PICV. Tested in accordance with EN12266-1:2012. Flow modulation along whole control actuator stroke (C21V, C22V, C23E). 5 year guarantee.

Connection

Screwed BSP Connections.

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass H Block with ART 22. Tested in accordance with EN12266-1:2012. 5 year guarantee.

Connection

Screwed BSP Connections.

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass H Block with ART 23 and ART 27. Tested in accordance with EN12266-1:2012. 5 year guarantee.

Connection

Screwed BSP Connections.

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

DZR Brass H Block with ART 26 and ART 27. Tested in accordance with EN12266-1:2012. 5 year guarantee.

Connection

Screwed BSP Connections.

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

PN16 DPCV (ART 24), Partner Valve (ART 28DP), and Impulse tube connection (ART 24IT1M /ART 24IT2M). Supplied as shown with fitting and measuring nipples. Handwheel shut-off function and clear 360° reading. Allen key locking mechanism enabling valve to be closed and re-opened to its exact pre-set position. Conforms to BS 7350 / BS 5154.

Connection

BSP Parallel (ART 24 - ISO 228/1. ART 28DP - ISO 7/1).

Approvals/ other

5 year guarantee

Pressure

16 Bar Rated

Temperature

-10°C to +120°C

Description

PN16 DPCV (ART 24C), Partner Valve (ART 28DP), and Impulse tube connection (ART 24IT1M /ART 24IT2M). Supplied as shown with fitting and measuring nipples. Handwheel shut-off function and clear 360° reading. Allen key locking mechanism enabling valve to be closed and re-opened to its exact pre-set position. Conforms to BS 7350 / BS 5154.
ART 24C bimstore link - https://www.bimstore.co/products/art-24c-dpcv-partner-valve
ART 28DP bimstore link - https://www.bimstore.co/products/art-28dp

Connection

BSP Parallel (ART 24C - ISO 228/1. ART 28DP - ISO 7/1).

Approvals/ other

5 year guarantee

Pressure

16 Bar Rated

Temperature

-10°C to +120°C

Description

Pressure Reducing Valve with gauge. Controls static and dynamic pressure. Designed and manufactured to BS EN 1567. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter. Supplied with a pressure gauge.

Connection

BSP Parallel Male Ends (ISO 228/1)

Pressure

Max Inlet Pressure: 16 Bar
Outlet Pressure range: 0.5 - 6 Bar
Minimum Inlet Pressure: 1 Bar
Factory Set Pressure: 3 Bar

Temperature

0°C to +80°C

Description

Pressure Reducing Valve with Gauge. Supplied with loose pressure gauge.

Connection

Compression ends (BS EN1254-2)
22mm with 15mm adaptors (adaptors supplied loose)

Approvals/ other

WRAS Approved
Conforms to BS EN 1567.

Pressure

See product datasheet.

Temperature

Max inlet temperature: 80°C

Description

Pressure Reducing Valve with gauge. Sizes available 1" - 2" BSP Parallel Male Ends. Controls static and dynamic pressure. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter.

Connection

BSP Parallel Male Ends (ISO 228/1)

Approvals/ other

WRAS Approved
Conforms to BS EN 1567

Pressure

See product datasheet.

Temperature

Max inlet temperature: 80°C

Description

Pressure Reducing Valve with gauge. Sizes 1/2" and 3/4" available BSP Parallel Female Ends. Controls static and dynamic pressure. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter.

Connection

BSP Parallel Female Ends

Approvals/ other

WRAS Approved.
Conforms to BS EN 1567.

Pressure

See product datasheet.

Temperature

Max inlet temperature: 80°C

Description

Pressure Reducing Valve with gauge. Controls static and dynamic pressure. Designed and manufactured to BS EN 1567. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter. Supplied with a pressure gauge.

Connection

BSP Parallel Male Ends (ISO 228/1)

Pressure

Max Inlet Pressure: 16 Bar
Outlet Pressure range: 0.5 - 6 Bar
Minimum Inlet Pressure: 1 Bar
Factory Set Pressure: 3 Bar

Temperature

Pressure Reducing Valve with gauge. Controls static and dynamic pressure. Designed and manufactured to BS EN 1567. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter. Supplied with a pressure gauge.

Description

Pressure Reducing Valve with Gauge. Supplied with loose pressure gauge.

Connection

Compression ends (BS EN1254-2)
22mm with 15mm adaptors (adaptors supplied loose)

Approvals/ other

WRAS Approved
Conforms to BS EN 1567.

Pressure

See product datasheet.

Temperature

Pressure Reducing Valve with Gauge. Supplied with loose pressure gauge.

Description

Pressure Reducing Valve with gauge. Sizes available 1" - 2" BSP Parallel Male Ends. Controls static and dynamic pressure. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter.

Connection

BSP Parallel Male Ends (ISO 228/1)

Approvals/ other

WRAS Approved
Conforms to BS EN 1567

Pressure

See product datasheet.

Temperature

See product datasheet.

Description

Pressure Reducing Valve with gauge. Sizes 1/2" and 3/4" available BSP Parallel Female Ends. Controls static and dynamic pressure. Easy to service high temperature cartridge. AISI 304 stainless steel cartridge filter.

Connection

BSP Parallel Female Ends (ISO 228/1)

Approvals/ other

WRAS Approved.
Conforms to BS EN 1567.

Pressure

See product datasheet.

Temperature

Max inlet temperature: 80°C

Description

DZR Brass Single Check Valve. F/F BSP Parallel (ISO 228/1). Conforms with EN13959. Suitable for Fluid Categories 1 & 2

Connection

F/F BSP Parallel (ISO 228/1)

Pressure

16 Bar Rated

Temperature

DZR Brass Single Check Valve. F/F BSP Parallel (ISO 228/1). Conforms with EN13959.

Description

DZR Brass Single Check Valve. Compression Ends (EN1254-2). Conforms with EN13959. Suitable for Fluid Categories 1 & 2.

Connection

Compression Ends (EN1254-2)

Approvals/ other

Conforms with EN13959

Pressure

10 Bar Rated

Temperature

Max Working Temp: +85°C

Description

DZR Brass Double Check Valve BSP Parallel F/F Ends. WRAS Approved. Conforms with EN13959. Suitable for Fluid Categories 1, 2 & 3.

Connection

BSP Parallel (ISO 228/1)

Approvals/ other

WRAS Approved

Conforms with EN13959.

Pressure

16 Bar Rated

Temperature

DZR Brass Double Check Valve BSP Parallel F/F Ends. 16 Bar Rated. -10°C to +85°C. WRAS Approved. Conforms with EN13959.

Description

DZR Brass Double Check Valve. Compression Ends. WRAS Approved. Conforms with EN13959. Suitable for Fluid Categories 1, 2 & 3.

Connection

Compression Ends

Approvals/ other

WRAS Approved.
Conforms with EN13959

Pressure

10 Bar Rated

Temperature

-10°C to +85°C

Description

Thermostatic Balancing Valve with Anti Legionella Device. WRAS Approved. Fluid: Water. Automatic legionella disinfectant feature. Improves efficiency of DHW systems. Automatic regulation. Reduces heat loss through lower circulation of hot water. Helps to keep temperature evenly distributed and reduces dead-legs.

Connection

BSP Parallel (ISO 7/1)

Approvals/ other

WRAS Approved

Pressure

Max working pressure (Static): 25 Bar

Temperature

Working temperature: 40°C to 60°C
Max Inlet temperature: 90°C
Anti Legionella temperature: 70°C
